Jacketed Ceramic Heaters

Name: Jacketed Ceramic Heaters
Brand: HEATING DEVICES

Get a Price/Quote

MOQ : 6 Pieces

Jacketed Ceramic Heaters Specification

Usage & Applications
Plastic injection & extrusion machines, Blow molding & processing machines, OEM heating equipment

Type
Jacketed Ceramic Heater

Material
High Grade Nickel Chromium Wire with Ceramic Beads & Stainless Steel Sheath

Capacity
Designed up to 300C surface temperature

Voltage
110-440 V (as per requirement)

Power
500 W to 3 kW (customizable)

Power Source
Electric

Input Voltage
110-440 V

Installation Type
Clamping with clamp or tightening mechanism

Dimension (L*W*H)
Custom sizes available (example: 100mm x 50mm x 50mm)

Weight (kg)
Varies with size (example: 1 kg to 5 kg)

Color
Silver / Grey

Resistance Tolerance
±10%

Connection Type
Cable, Terminal Box, Lugs, or Plug as required

Sheath Material
Stainless Steel (SS 304/316)

Inner Diameter
Customizable as per barrel size

Mounting Option
Clamping band with adjustable fastener

Surface Load
3.5-4.5 W/cm²

Protection
Earth connection provided for user safety

Max Operating Temperature
Up to 700°C

Lead Wire Length
Standard 1 meter, customizable

Heating Element Type
Nickel Chromium (NiCr) wire

Insulation
High Purity Ceramic Beads

Jacketed Ceramic Heaters Trade Information

Minimum Order Quantity
6 Pieces

FOB Port
GHAZIABAD

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
1 Week

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
CE

About Jacketed Ceramic Heaters

Jacketed Ceramic Heaters

Standard sizes with 20 different diameters ranging from 6.0 mm to 25 mm and lengths from 40 mm to 500 mm. The heating power of these cartridge heaters ranges between 100 and 4000 watts.

You will get superior quality Jacketed Ceramic Heaters here at Heating Devices. These are utilized for heating cylinders in different processing machinery. In addition to this, the said devices are found in commercial and industrial areas. Our offered products are appreciated for their unique features, stylish structure and long lasting service life. These are known for consuming less power as well as requiring low maintenance. Jacketed Ceramic Heaters are accessible in different specifications, designs, sizes and shapes. These are insulated and assure protection from shock, corrosion or rust. Furthermore, the said devices have strong construction, simple features and smooth functioning.

High Performance Heating for Industrial Applications

Jacketed Ceramic Heaters are engineered for demanding industrial processes. Their sophisticated construction allows them to withstand high temperatures and surface loads while ensuring energy-efficient operation. With customizable dimensions, power outputs, and mounting options, they seamlessly integrate into plastic processing and OEM heating systems, maximizing productivity and safety.

Durable Construction & Reliable Operation

With a stainless steel sheath and high-purity ceramic insulation encapsulating a Nickel Chromium wire, these heaters offer exceptional durability and longevity. The robust clamping band with an adjustable fastener ensures secure installation, and optional terminal protection enhances user safety. Earth connection further safeguards operators against electrical hazards.

FAQs of Jacketed Ceramic Heaters:

Q: How do you install a jacketed ceramic heater on a machine barrel?

A: Jacketed ceramic heaters are typically installed using a clamping band and adjustable fastener, which securely attach the heater to the barrel. The mounting system allows for easy adjustment to fit various diameters. Ensure the heater matches your barrel size, connect the wiring as required via cable, lugs, plug, or terminal box, and verify the earth connection for safe operation.

Q: What are the primary benefits of using a NiCr wire ceramic heater with stainless steel sheath?

A: Nickel Chromium wire ensures rapid heating and excellent longevity, while the stainless steel sheath resists corrosion and enhances heat transfer. The ceramic bead insulation provides uniform heat distribution and electrical isolation, making the heater highly efficient and safe for high-temperature industrial use.

Q: When should I consider customizing the dimensions or power of the heater?

A: Customization is recommended when standard sizes or power outputs dont match your machinery requirements. Specify custom inner diameters, lengths, widths, or power ratings to ensure optimal contact, heat transfer, and performance for unique or non-standard applications, such as OEM equipment or specialized machines.

Q: Where are jacketed ceramic heaters commonly used?

A: These heaters are widely used in plastic injection and extrusion machines, blow molding and processing technologies, and various OEM heating equipment. Their resilience at high temperatures and customizable fit make them suitable for diverse industrial settings, particularly in the plastics and packaging sectors.

Q: What process ensures user safety during heater operation?

A: An earth connection is provided to prevent electrical hazards, ensuring user safety during operation. Additionally, the heaters incorporate robust insulation and a protective sheath, while installation via clamps or terminals further minimizes risk when correctly configured.

Q: How does the resistance tolerance of 10% affect heater performance?

A: A resistance tolerance of 10% ensures that the heating element operates within acceptable electrical parameters, balancing efficient heat generation with longevity. This range accommodates minor manufacturing variations without compromising heater performance or safety.
